Mini Size Flow Switch, Brass Upper and Lower Body, 2" NPT, Less Tee, SPDT Switch, Explosion Proof

Dwyer V6EPB-B-S-6-0 Flow Switch – Mini Size, 2" NPT, Brass Body, SPDT, Explosion Proof

The Dwyer Instruments V6EPB-B-S-6-0 is a compact and durable mini-size flow switch from the trusted V6 Series, designed to reliably monitor liquid, gas, or air flow in industrial and commercial applications. Built with a brass upper and lower body, this switch features 2" NPT mounting, a SPDT snap switch, and an explosion-proof housing, making it ideal for demanding environments.

Key Features:

• Manufacturer Part Number: V6EPB-B-S-6-0

• Brand: Dwyer Instruments

• Mounting Type: 2" NPT

• Switch Type: SPDT (Single Pole, Double Throw)

• Material: Brass Upper and Lower Body

• Explosion Proof: Yes – suitable for hazardous locations

• IP Rating: IP65 – Dust-tight and water-resistant

• Compact Design: Mini size for space-saving installations

• Series: V6 Flotect Series

• Flow Activation: Magnetically actuated, no mechanical linkage

• Operating Principle: Flow forces vane against spring; when flow decreases, the spring actuates the switch to trigger alarms or shutoff

Applications:
Ideal for use in HVAC systems, fluid handling, process control, oil & gas, and chemical processing. This Dwyer flow switch is commonly installed in pipelines to trigger alarms, shutdown systems, or automate equipment based on flow conditions.

Why Choose the Dwyer V6 Series?
The V6EPB-B-S-6-0 offers dependable, maintenance-free operation in compact form, with a rugged build and explosion-proof protection—ensuring safety, precision, and long-term value.
